Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder

Dettagli:

Luogo di origine:	Taiwan, Cina
Marca:	Mindman, AIRWOLF or OEM
Certificazione:	CE, ISO9001
Numero di modello:	MCJA-11-12-25, MCJA-11-12-30, MCJA-11-16-5, MCJA-11-16-10

Termini di pagamento e spedizione:

Quantità di ordine minimo:	1 pezzo
Prezzo:	5-63USD
Imballaggi particolari:	Scatole, cartoni, pallet, sacchetti di plastica
Tempi di consegna:	1-7 giorni lavorativi
Termini di pagamento:	T/T, Western Union, PayPal
Capacità di alimentazione:	1000 pezzi a settimana

Contatto

Descrizione di prodotto dettagliata

Codice articolo:	MCJA-11-12-25, MCJA-11-12-30, MCJA-11-16-5, MCJA-11-16-10	Materiale del corpo:	Lega di alluminio
Materiale di imballaggio del pistone:	NBR	Pressione di esercizio:	0,05~1MPa
Temperatura operativa:	-5~+60℃ (senza congelamento)	Mezzo di lavoro:	Aria
Dimensione del foro:	12,16 mm	Funzione:	Doppio recitazione
Evidenziare:	Double acting compact air cylinder , Pneumatic compact cylinder with warranty , MCJA series double acting cylinder

Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder

Built from carefully selected aluminum alloy with hard-anodized treatment, the MCJA body resists wear and corrosion in continuous-duty pneumatic systems, while the extruded profile integrates a peripheral sensor groove that lets proximity switches mount flush and adjust position without external brackets. Installation relies on countersunk-hole tooth mounting, so the cylinder sits directly against the fixture without extra foot brackets, cutting parts count and keeping the envelope tight around the actuator itself.

Order Codes:

Item Code	Piston (mm)	Stroke (mm)	Type
MCJA-11-12-25	12	25	Double acting
MCJA-11-12-30	12	30	Double acting
MCJA-11-16-5	16	5	Double acting
MCJA-11-16-10	16	10	Double acting

Specification:

Model		MCJA
Acting type		Double acting / Single acting							Double acting
Tube I.D. (mm)		12	16	20	25	32	40	50	63	80	100
Port size		M5×0.8				Rc1/8		Rc1/4			Rc3/8
Medium		Air
Operatingperssurerange (MPa)	Double acting	0.05~1		0.03~1		0.02~1
	Single acting	0.2~1		0.15~1		0.1~1			—
Proof pressure		1.5 MPa
Ambient temperature		-5°C~+60°C (No freezing)
Available speed range		50~500 mm/sec

Material:

Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder

Dimensions:

Mindman MCJA-11-12-25 MCJA-11-12-30 MCJA-11-16-5 MCJA-11-16-10 Double acting Compact Cylinder
